Metal Bottom Plate Ultralight for ALIGN T-Rex 700 Electric Series Helicopters

Product has been archived, and is no longer available for purchase. This page is for reference only.



The Metal Bottom Plate Ultralight design provides an FEA-optimized, aluminum 6061-T6 crossbar construction that prevents flex during high-torque maneuvers of both the helicopter lower frame section and the connected tail boom braces. Compatible with all T-Rex 700 Electric Series helicopters (DFC and V1/V2), the new upgrade provides unprecedented strength in an ultralight design, weighing only 62 grams (~17 grams less than the stock DFC edition).


Material: Aluminum 6061-T6

Models: All ALIGN T-Rex 700 series.


  • One (1) T-Rex 700 Series Aluminum Metal Bottom Plate Ultralight
  • Twelve (12) M3 x 0.5 x 8 mm Socket Head Cap Screws (Class 12.9)
  • Two (2) M4 x 0.7 x 16 mm Socket Head Cap Screws (Class 12.9)

Finish: Clear anodize, mirror-polish CNC gloss

Weight: 62 g (design is FEA optimized for maximum strength and minimum weight)
